Floor Heating Mat

Floor Heating Mat
Price : INR 250.00 - 450.00 / SqFeet
Buy Now

MOQ : 100 Sq. Feet

Business Type Manufacturer, Exporter, Supplier, Retailer, Wholesaler
Color All Color
Application Table Use
Feature Easy Washable, Great Designs, Mesmerizing Look, Water Proof

Preferred Buyer From

Location Worldwide

Under Floor Heating Mat


  • Dimensions –all mats are 0.5m wide.
  • Lengths available: 1mtr – 24 mtr,
  • Rating Voltage: 110/230-240 vac
  • Power unit: 150/165/200/225 Watt/m², +/-10% Min. bending radius: 30mm
  • Min. cable space: 75mm
  • Max. Ambient temperature: 40ºC Min. installation temperature: 5ºC
  • Heating cable: Twin wires, grounded, insulation jacket by PTFE (Teflon) Insulation.
  • Connecting leads: 2 Core 1.5 Sq.mm with grounded braid, length 3mtr
  • 10 Year Guarantee on the Heating mat
    (Valid if only in accordance with our instructions and all other conditions detailed in the warranty).
  • All components comply fully with all relevant Tests and measurement as per Standard.


These Floor Heaters are designed for a variety of applications. Modern underfloor heating systems use electrical resistance elements (“electric systems”) to heat the floor. This type can be installed as the primary, whole-building heating system or as localized floor heating for thermal comfort. Under floor heating is a form of central heating which achieves indoor climate control for thermal comfort. Floor heating systems are used only for heating and employ non-corrosive, flexible heating elements including cables, pre-formed cable mats. Due to their low profile they can be installed in a thermal mass or directly under floor finishes. Electric systems can also take advantage of time of-use electricity metering and are frequently used as carpet heaters, portable under area rug heaters, under laminate floor heaters, under tile heating, under wood floor heating, and floor warming systems, including under shower floor and seat heating.

Benefits of Electric Underfloor Heating mat


  • Heat is spread evenly across the whole floor area
  • This provides a more comfortable climate for you wherever you are in the room. (Easy to install)
  • With no water pipes involved, there is no danger of leaks so you don’t have to worry about damage to your property.
  • There are cost savings too, as there is no need for any kind of maintenance contract as once the systems are installed they can be forgotten about for years to come.
  • Children friendly.
  • With no moving parts involved in floor heating, so no more scary noises in the night.

Yes! I am interested

150 Watt/m² Heating Mat

Sl. No. Part No. Mat Size Area Sq. mtr/Feet Watt.
1 HTT150/1 0.50×2 mtr 45302 150
2 HTT150/1.5 0.50x3mtr 1.5/16 225
3 HTT150/2 0.50x4mtr 45344 300
4 HTT150/2.5 0.50x5mtr 2.5/27 375
5 HTT150/3 0.50x6mtr 12114 450
6 HTT150/3.5 0.50x7mtr 3.5/39 525
7 HTT150/4 0.50x8mtr 16163 600
8 HTT150/4.5 0.50x9mtr 4.5/50 675
9 HTT150/5 0.50x10mtr 20210 825
10 HTT150/6 0.50x12mtr 24259 900
11 HTT150/7 0.50x14mtr 28672 1050
12 HTT150/8 0.50x16mtr 33086 1200
13 HTT150/9 0.50x18mtr -657192 1350
14 HTT150/10 0.50x20mtr -653145 1500
15 HTT150/11 0.50x22mtr -649096 1650
16 HTT150/12 0.50x24mtr -645048 1800

165 Watt/m² heating mat

      Area Sq.
Sl. No. Part No. Mat Size mtr/Feet Watt.
1 HTT165/1 0.50×2 mtr 01-Nov 165
2 HTT165/1.5 0.50x3mtr 1.5/16 250
3 HTT165/2 0.50x4mtr Feb-22 330
4 HTT165/2.5 0.50x5mtr 2.5/27 410
5 HTT165/3 0.50x6mtr Mar-33 495
6 HTT165/3.5 0.50x7mtr 3.5/39 578
7 HTT165/4 0.50x8mtr Apr-44 660
8 HTT165/4.5 0.50x9mtr 4.5/50 743
9 HTT165/5 0.50x10mtr May-55 825
10 HTT165/6 0.50x12mtr Jun-66 990
11 HTT165/7 0.50x14mtr Jul-78 1150
12 HTT165/8 0.50x16mtr Aug-90 1320
13 HTT165/9 0.50x18mtr -657192 1485
14 HTT165/10 0.50x20mtr -653145 1650
15 HTT165/11 0.50x22mtr -649096 1800
16 HTT165/12 0.50x24mtr -645048 1980
